Ankle Mortise: Anatomy, Radiographic Measurements, and Fracture Assessment

The ankle mortise is the bony socket formed by the distal tibia, fibula, and the connecting syndesmosis that houses and constrains the dome of the talus during all weight-bearing and ankle motion. The term describes the shape: the tibia forms the roof (tibial plafond) and medial wall (medial malleolus), the fibula forms the lateral wall (lateral malleolus), and the interosseous ligament and syndesmotic ligaments bind the tibia and fibula together to form a stable three-sided socket. Maintenance of mortise congruity — the precise fit of the talar dome within the three walls of the socket — is the fundamental goal of all ankle fracture treatment, because even 1mm of lateral talar shift increases tibiotalar contact stress by approximately 40% and dramatically accelerates post-traumatic arthritis. Assessment of mortise congruity on the mortise view X-ray (15-20° internal rotation AP) is the critical diagnostic step for every ankle fracture and ankle instability evaluation.

Ankle Mortise: Anatomy, Measurements, and Radiographic Assessment

Structure	Anatomy	Role in Mortise Stability	Injury Consequence
Tibial plafond (roof)	Distal tibial articular surface; concave to match convex talar dome; accounts for approximately 60% of total ankle load transmission; the metaphyseal flare transitions to the plafond above	Primary load-bearing surface of the mortise; congruity with talar dome essential for distributed load; posterior tibial lip (posterior malleolus) extends the articular surface posteriorly	Pilon fracture (high-energy axial load fractures the plafond itself); posterior malleolus fracture (reduces posterior articular coverage of the talus); plafond articular incongruity produces rapid post-traumatic arthritis
Medial malleolus	Medial bony projection of the distal tibia; articulates with the medial facet of the talus; deltoid ligament attaches to its tip and posterior colliculus; provides medial constraint to the talus	Medial wall of mortise; prevents medial and lateral talar shift; together with the deltoid ligament forms the medial restraint system	Medial malleolus fracture removes medial bony constraint; deltoid ligament tear (without fracture) also destabilizes medial wall; either allows lateral talar shift, producing mortise widening
Lateral malleolus (fibula)	Distal fibula; lateral wall of mortise; articulates with the lateral facet of the talus; ATFL and CFL attach anteriorly and inferiorly; syndesmosis (AITFL, PITFL, IOM) connects fibula to tibia proximally	Primary lateral constraint; maintains mortise width; fibula position determines talar width accommodation — fibular shortening or displacement allows lateral talar shift even without medial injury	Fibula fracture (Weber A/B/C) disrupts lateral wall; any lateral malleolus displacement or shortening narrows or widens the mortise; lateral talar shift by even 1mm increases plafond contact stress 40%
Syndesmosis (tibiofibular ligament complex)	AITFL (anterior inferior tibiofibular ligament), PITFL (posterior inferior tibiofibular ligament), and interosseous ligament (IOM); bind fibula to tibia in the distal 2-3cm; maintain the precise distal tibiofibular relationship (tibiofibular clear space and overlap on X-ray)	Holds the mortise width constant; prevents widening of the tibiofibular articulation that would allow lateral talar displacement; the most commonly missed ankle injury in Weber B and C fractures	Syndesmotic disruption (high ankle sprain, Weber C fracture) allows the mortise to widen under load — talar width exceeds mortise width — producing instability not visible on non-stress X-rays; requires Cotton test or stress fluoroscopy to identify
Deltoid ligament	Medial ankle ligament complex with superficial and deep layers; deep deltoid is the primary medial restraint to lateral talar shift; superficial deltoid controls forefoot abduction	Medial soft tissue restraint; deep deltoid resists lateral talar translation and external rotation; functions in series with the lateral malleolus — both must be disrupted for mortise instability in most fracture patterns	Deltoid tear without medial malleolus fracture produces equivalent instability to medial malleolus fracture; medial clear space widening on mortise X-ray indicates deltoid or bony medial wall failure

Ankle Mortise Measurements: Normal Values and Pathological Thresholds

Measurement	Technique	Normal Value	Pathological Threshold	Significance
Medial clear space	Measured on mortise view (15-20° internal rotation AP) from medial border of talus to medial malleolus articular surface; measured at the level of the talar dome	Less than or equal to 4mm; should equal the superior clear space (tibiotalar joint space)	Greater than 4mm OR greater than superior clear space = abnormal	Medial clear space widening indicates medial-side injury (deltoid tear or medial malleolus fracture) and lateral talar shift; key indicator of mortise instability; differentiates stable from unstable Weber B fractures
Superior clear space (tibiotalar joint space)	Measured on mortise view from talar dome to tibial plafond; should be uniform across the entire joint	2-4mm; uniform across width	Asymmetric narrowing or widening; less than 2mm (joint space loss from arthritis); talar tilt (asymmetric space) indicates ligament disruption	Uniform superior clear space confirms congruent mortise; talar tilt (wider laterally than medially under stress) indicates lateral ligament disruption; narrowing indicates arthritis
Tibiofibular clear space	Measured on AP view at 1cm above the plafond; horizontal distance between the lateral border of the posterior tibial malleolus and medial border of fibula	Less than 5mm on AP view; less than 6mm on mortise view	Greater than 5mm (AP) or 6mm (mortise) = syndesmotic widening	Widened tibiofibular clear space indicates syndesmotic disruption (high ankle sprain or Weber C fracture); indicates mortise is wider than normal, allowing lateral talar displacement under load
Tibiofibular overlap	Measured on AP view at 1cm above plafond; the width of overlap between the medial fibula and lateral tibial shadow	Greater than 10mm on AP; greater than 1mm on mortise view	Less than 10mm (AP) or less than 1mm (mortise) = syndesmotic injury	Reduced or absent tibiofibular overlap on AP view indicates syndesmotic disruption and fibular displacement; used in conjunction with tibiofibular clear space for syndesmosis assessment
Talocrural angle	Angle between the tibial plafond line and a line perpendicular to the tibial shaft; measures fibular length relative to tibial plafond; both ankles compared	83 +/- 4 degrees; should be equal between ankles	Greater than 4 degree difference between ankles	Asymmetric talocrural angle indicates fibular shortening — fibula is too short relative to the plafond, allowing lateral talar shift even when other measurements appear normal; sensitive marker for fibular shortening in Weber fractures

At Balance Foot & Ankle in Howell and Bloomfield Township, the mortise view X-ray with precise measurement of medial clear space, superior clear space, tibiofibular clear space, and tibiofibular overlap is performed and formally documented for every ankle fracture evaluation — because treatment decisions for Weber B fractures hinge entirely on these measurements, and a mortise view taken without internal rotation produces inaccurate measurements that can lead to undertreatment of unstable fractures. Call (810) 206-1402.
