Foot Orthotics for Patellofemoral Pain: How Foot Mechanics Affect the Knee

Medically reviewed by Dr. Tom Biernacki, DPM — Board-Certified Podiatric Surgeon — Balance Foot & Ankle, Howell & Bloomfield Hills, MI. Last updated April 2026.

Patellofemoral pain syndrome (PFPS) — pain at the anterior knee from patellar maltracking in the femoral trochlear groove — is the most common knee complaint in sports medicine, accounting for 25–40% of all knee complaints in active populations. While patellofemoral pain is a knee diagnosis, the biomechanical chain contributing to abnormal patellar tracking frequently originates at the foot. The pathomechanical link is well-established: excessive foot pronation during stance generates internal tibial rotation, which — in a closed kinetic chain — produces internal femoral rotation and lateral patellar tilt, increasing patellofemoral contact stress. This is why foot orthotic therapy is a first-line treatment for PFPS in patients with demonstrable foot pronation.

The Kinetic Chain: Foot to Knee

During stance phase of gait, subtalar joint pronation (calcaneal eversion and talar adduction) is coupled with internal tibial rotation through the subtalar joint’s oblique axis. At the knee, internal tibial rotation beneath a relatively fixed femur increases the Q-angle (the angle between the line of force of the quadriceps tendon and the patellar tendon), laterally displacing the patella relative to the femoral trochlea. Simultaneously, internal femoral rotation from hip abductor weakness places the trochlear groove in a relatively more medial position — magnifying lateral patellar tilt. The cumulative effect is elevated lateral facet patellofemoral contact pressure, responsible for the anterior knee pain, crepitus, and peripatellar aching of PFPS.

Evidence for Foot Orthotics in PFPS

Multiple randomized controlled trials demonstrate foot orthotic therapy’s effectiveness for PFPS. Eng and Pierrynowski (1993) showed significantly greater pain reduction with custom foot orthotics compared to physical therapy alone at 3 months. Collins et al. (2008, BJSM) — the landmark “Foot Orthoses and Physiotherapy in the Treatment of Patellofemoral Pain Syndrome” trial — demonstrated that foot orthotics produced equivalent short-term outcomes to physiotherapy and that combined orthotics plus physiotherapy was superior to either alone. Prefabricated orthotics with medial arch support produce meaningful benefit for PFPS in many patients — custom orthotics provide superior correction for patients with significant pronation deformity or orthopedic complicating factors.

Orthotic Design for PFPS

Orthotics for PFPS target subtalar pronation control: a deep heel cup (greater than 14 mm) providing calcaneal rearfoot stability, a medial arch support that contacts the arch throughout the loading phase without triggering midfoot pain, medial forefoot posting (intrinsic wedging under the medial forefoot) to control first ray plantarflexion, and a rearfoot valgus post (extrinsic wedging under the medial heel) for patients with excessive calcaneal eversion. Rigid orthotics provide superior rearfoot control; sport-specific semi-rigid orthotics balance control with cushioning for runners and court sport athletes. The orthotic prescription must account for the specific sport and footwear — a distance running orthotic differs from a basketball orthotic in terms of heel thickness, arch flexibility, and surface material.

Concurrent Hip Strengthening

Orthotics and hip abductor/external rotator strengthening (gluteus medius, piriformis, short external rotators) work synergistically for PFPS — the orthotics reduce pronation-driven internal rotation from below while hip strengthening reduces internal femoral rotation from above. The strongest evidence for PFPS treatment combines foot orthotic therapy with hip-focused physical therapy rather than either alone. Patients with PFPS presenting to podiatry for orthotic evaluation should be co-managed with physical therapy for comprehensive kinetic chain rehabilitation.

Orthotics for Knee Pain at Balance Foot & Ankle

Dr. Biernacki at Balance Foot & Ankle evaluates patients with patellofemoral and knee pain from a podiatric biomechanics perspective — identifying subtalar pronation, tibial torsion, and foot type contributions to knee loading patterns. Custom orthotics are fabricated using 3D digital foot scanning and biomechanical evaluation. Call (810) 206-1402 for an evaluation of knee pain related to foot mechanics.

Knee Pain From Foot Problems? Custom Orthotics May Help.

Serving Southeast Michigan from Bloomfield Hills and Howell.

📞 (810) 206-1402 |

📧 Get Dr. Tom’s Free Lab Test Guide

Discover the 5 lab tests every person over 35 should ask their doctor about — explained in plain English by a board-certified physician.

Download Your Free Guide →

Book Online →

📍 Located in Michigan?

Our board-certified podiatrists treat this condition at two convenient locations. Same-day appointments often available.

Book Now →
(810) 206-1402

Custom Orthotics for Knee Pain in Michigan

Foot orthotics can significantly reduce patellofemoral (kneecap) pain by correcting lower extremity alignment. Our podiatrists address the foot-knee biomechanical connection.

Explore Our Custom Orthotic Solutions → | Book Your Appointment | Call (810) 206-1402

Clinical References

1. Collins N, Crossley K, Beller E, Darnell R, McPoil T, Vicenzino B. Foot orthoses and physiotherapy in the treatment of patellofemoral pain syndrome: randomised clinical trial. BMJ. 2008;337:a1735.
2. Barton CJ, Munteanu SE, Menz HB, Crossley KM. The efficacy of foot orthoses in the treatment of individuals with patellofemoral pain syndrome: a systematic review. Sports Med. 2010;40(5):377-395.
3. Powers CM. The influence of abnormal hip mechanics on knee injury: a biomechanical perspective. J Orthop Sports Phys Ther. 2010;40(2):42-51.
