Gait Phase	Normal Event	Common Deviation	Clinical Consequence
Initial Contact	Lateral heel strike; 1–2° supination	Overpronation at contact; forefoot strike in runners	Increased medial knee stress; tibial internal rotation
Loading Response	Controlled pronation 4–6°; shock absorption	Excessive pronation (>6°); rapid pronation velocity	Plantar fasciitis; posterior tibial tendinopathy; medial shin splints
Midstance	Subtalar neutral; arch loaded; tibia vertical	Persistent pronation; Trendelenburg drop	IT band syndrome; lateral knee pain; forefoot overload
Terminal Stance / Propulsion	Heel rise; resupination; 1st ray plantarflexion	Insufficient resupination; delayed heel rise; hallux limitus	Sesamoiditis; plantar plate injury; 2nd MT stress fracture
Swing Phase	Adequate dorsiflexion; neutral foot carriage	Foot drop; circumduction; steppage gait	Peroneal nerve palsy; tibial nerve dysfunction

Finding	Gait Correlation	Orthotic Strategy	Shoe Recommendation
Rearfoot valgus >4° (overpronation)	Excessive subtalar pronation; medial collapse	Medial heel post; arch fill; semi-rigid shell	Stability or motion-control shoe
Rearfoot varus (underpronation)	Rigid supination; lateral overload	Lateral heel post; cushioning orthotic	Neutral shoe with cushioning; avoid motion-control
Forefoot valgus	Pronation to load forefoot; late midstance collapse	Forefoot valgus post	Neutral stability shoe
Equinus (<5° dorsiflexion)	Early heel rise; compensatory pronation or knee flexion	Heel lift 6mm; gastroc stretching protocol	Heel-to-toe drop >8mm; avoid zero-drop
Leg length discrepancy >5mm	Ipsilateral pronation; contralateral supination; pelvic obliquity	Heel lift on short side	Address footwear symmetrically

https://www.youtube.com/watch?v=8opvH3qxkW4

If you’re a runner who keeps getting injured — the same knee pain, the same plantar fasciitis, the same shin splints — there’s likely a biomechanical reason behind it. Your body doesn’t make random errors; it compensates for structural and functional imbalances in predictable ways, and these compensations eventually cause injury. A professional biomechanical assessment by a sports-focused podiatrist cuts through the guesswork, identifies the root cause of recurring problems, and guides a targeted treatment plan.

What Is a Biomechanical Assessment?

A podiatric biomechanical assessment is a hands-on exam plus imaging when needed of the static and dynamic mechanics of the foot, ankle, leg, and lower extremity. It goes far beyond just watching someone walk. A thorough assessment includes static evaluation of foot structure (arch height, rearfoot alignment, forefoot position, digital alignment), joint range of motion testing (ankle dorsiflexion, subtalar motion, first MTP range), muscle strength testing (posterior tibialis, peroneal, intrinsic foot muscles, hip abductors), and lower extremity alignment assessment (leg length discrepancy, Q-angle, tibial torsion).

Gait Analysis: Walking and Running

Dynamic gait analysis evaluates how the foot functions under load during walking and running. Key observations include heel strike pattern (rearfoot, midfoot, or forefoot striker), degree and timing of pronation during stance phase, push-off pattern, and symmetry between limbs. Video gait analysis allows frame-by-frame review of movement patterns from multiple angles. Pressure mapping (pedobarography) provides objective data on how pressure distributes across the foot during gait — identifying hot spots and asymmetries that cannot be seen by eye alone.

Common Findings and What They Mean

Overpronation (excessive inward rolling of the foot) increases tibial rotation, contributes to medial knee stress, plantar fasciitis, posterior tibial tendinopathy, and shin splints. It is addressed with motion-control footwear, medial posting orthotics, and hip/ankle strengthening.

Supination (underpronation, outward rolling) reduces the foot’s natural shock absorption, increasing stress fracture risk, lateral ankle injuries, and iliotibial band syndrome. It is managed with neutral or cushioned footwear and lateral forefoot posting.

Equinus (limited ankle dorsiflexion from tight calves or Achilles) forces the foot to compensate by pronating excessively or the knee to flex early — contributing to plantar fasciitis, Achilles tendinopathy, and metatarsalgia. Treatment includes intensive calf stretching and sometimes orthotic modifications.

Leg length discrepancy (one limb longer than the other) creates asymmetric loading that can cause hip, knee, or foot pain on the longer or shorter side. Even a 4–6mm discrepancy can be clinically significant in runners covering high mileage.

What Comes Out of a Gait Analysis

A completed biomechanical assessment produces a clear, individualized treatment plan. This typically includes custom orthotic prescription (with specific posting, arch height, shell material, and forefoot modifications tailored to the findings), footwear recommendations (category, width, heel drop, cushion level), physical therapy referral for specific muscle imbalances, and running form modifications where indicated. For some runners, small footwear changes alone produce dramatic improvement. For others, a custom orthotic is the keystone of injury prevention.

Who Should Get a Gait Analysis?

Any runner with recurrent injuries should consider a professional gait analysis. Other good candidates include beginning runners who want to start injury-free, runners training for their first marathon or high-mileage event, athletes transitioning to barefoot or minimal shoes, and anyone who has tried multiple treatments for a foot or lower extremity problem without lasting success.
