AFO Type	Construction	Motion Allowed	Primary Indication	Activity Level
Solid AFO	Rigid polypropylene; fixed ankle	None — fixed position	Foot drop; severe spasticity; severe instability	Community ambulation; limited sport
Articulated AFO	Rigid uprights + mechanical ankle joint	Dorsiflexion assisted; plantarflexion limited	Foot drop with need for push-off; peroneal palsy	Active community; rehabilitation
Posterior Leaf Spring (PLS)	Flexible polypropylene; trimmed posterior	Some dorsiflexion; flexible resistance	Mild foot drop; mild spasticity; partial peroneal nerve	Active; outdoor ambulation
CROW (Charcot Restraint Orthotic Walker)	Total contact; bivalved clamshell	Minimal — total contact immobilization	Charcot foot; severe neuropathic deformity	Protected ambulation only
Carbon Fiber AFO (Dynamic)	Carbon fiber energy-return spring	Dynamic dorsiflexion resistance; energy return	Active patients with foot drop; sports; lightweight needs	Active; athletic
Arizona / Gauntlet AFO	Leather + metal uprights; lace-up	Limited; accommodative	PTTD Stage II; ankle arthritis; moderate instability	Daily activity; work

Condition	Recommended AFO Type	Goal	Footwear Requirement
Foot Drop (Peroneal Palsy)	Posterior leaf spring or articulated AFO	Clear foot during swing phase; prevent tripping	Extra-depth shoe with removable insole; AFO replaces insole space
Charcot Foot (Acute Stage II–III)	CROW brace	Total contact; immobilize foot; prevent further collapse	Worn without shoe; custom CROW is the footwear
Posterior Tibial Tendon Dysfunction (Stage II)	Arizona (Gauntlet) AFO or UCBL orthosis	Supports arch; prevents flatfoot progression	Extra-depth wide shoe; accommodates medial support
Chronic Ankle Instability	Articulated AFO or lace-up brace	Limits inversion; proprioceptive support	High-top athletic shoe for mild instability; extra-depth for AFO
Spastic Equinus (CVA / MS)	Solid AFO (set at 90°) or dynamic carbon fiber	Prevents foot drop and equinus contracture; improves gait	Wide toe-box shoe; extra-depth for AFO bulk

https://www.youtube.com/watch?v=8opvH3qxkW4

A custom ankle-foot orthosis (AFO) is a brace that extends from just below the knee to under the foot, providing controlled support for the ankle and foot. Unlike prefabricated off-the-shelf braces, custom AFOs are fabricated from a precise cast or 3D scan of the patient’s limb, providing superior fit, comfort, and biomechanical control. Dr. Biernacki prescribes and fits custom AFOs for a range of foot and ankle conditions that require more support than standard orthotics can provide.

When Is an AFO Recommended?

AFOs are prescribed for conditions that involve significant ankle or foot muscle weakness, instability, or arthritic pain that standard orthotics cannot adequately address. Common indications include: foot drop (peroneal nerve palsy causing inability to dorsiflex the ankle, leading to tripping and falls); posterior tibial tendon dysfunction (PTTD) and adult acquired flatfoot where the arch has collapsed significantly; chronic ankle instability that has failed conservative bracing; ankle arthritis where load reduction through an AFO reduces pain with walking; Charcot foot in diabetic patients; and neurological conditions (cerebral palsy, stroke, multiple sclerosis) with lower extremity spasticity or weakness.

Types of Custom AFOs

Not all AFOs are the same — the design is tailored to the patient’s condition and function goals. Solid AFO: A rigid brace that locks the ankle in a fixed position — used for severe foot drop or when ankle motion must be completely controlled. Hinged AFO: Allows controlled dorsiflexion while preventing plantarflexion — ideal for foot drop patients who want more natural gait mechanics. Posterior leaf spring (PLS) AFO: A flexible plastic brace that provides dorsiflexion assist while allowing some ankle motion — the most commonly prescribed AFO for mild-moderate foot drop. Floor-reaction AFO: A rigid anterior brace that uses ground reaction force to control knee extension — used in patients with quadriceps weakness. Dynamic AFO: Carbon fiber or fiberglass designs that store and return energy during walking — popular with athletic patients who need AFO support with minimal weight penalty.

The Custom AFO Fitting Process

Custom AFO fabrication begins with a thorough evaluation of the patient’s condition, gait pattern, footwear preferences, and activity goals. A cast or 3D scan of the foot and lower leg in the prescribed position is taken. This impression is sent to a certified orthotics laboratory where the AFO is custom fabricated. At the fitting appointment, Dr. Biernacki or a certified orthotist assesses the fit, checks for pressure points, and makes in-house modifications as needed. Most custom AFOs require 2-3 weeks for fabrication. Insurance typically covers custom AFOs when medically necessary with proper documentation.
