Diagnosis	Location	Onset	X-ray	MRI / Ultrasound	Key Differentiator
Insertional Achilles Tendinopathy	Distal 2 cm at calcaneal insertion	Gradual overuse; peak activity changes	Intratendinous calcification at insertion; posterior calcaneal spur (Haglund)	Tendon thickening; intratendinous signal change; enthesopathy	Pain and tenderness at bony insertion; worse first steps and at end of day
Non-Insertional (Midportion) Achilles Tendinopathy	2-6 cm proximal to insertion	Gradual overuse; runners	Normal; no calcification	Tendon thickening; neovascularization; fusiform swelling	Pain in tendon body 4-6 cm above heel; spindle-shaped thickening
Retrocalcaneal Bursitis	Between Achilles tendon and posterior calcaneus	Shoe counter pressure; activity	May show Haglund deformity	Fluid-filled bursa on MRI; enhancing on contrast	Pain deep to Achilles; two-finger squeeze test positive
Insertional Achilles Calcific Tendinopathy	At insertion; within tendon substance	Can be acute exacerbation in chronic tendinopathy	Dense calcification within distal tendon	Dense calcium deposit on ultrasound; shadowing	Dense X-ray calcification; calcific deposits disrupt tendon structure

Treatment	Evidence	Protocol	Success Rate	Timeframe
Heel Lift + Eccentric Loading (modified)	Level II	Modified eccentric protocol (concentric-eccentric; avoid painful range); heel lift 10-12 mm	60-70% (less than non-insertional response to eccentrics)	12 weeks minimum
ESWT (Shockwave Therapy)	Level I	3-5 sessions; focused or radial; calcification fragmentation	70-85% at 12 weeks; superior to eccentrics alone for calcific disease	3-5 weekly sessions
Corticosteroid Injection (peritendinous)	Level III	Peritendinous only (never intratendinous); ultrasound-guided	Short-term relief; significant tendon rupture risk	Use with extreme caution; max 1 injection
PRP Injection	Level II	Ultrasound-guided PRP at insertion; 1-2 injections	65-75% improvement; more durable than cortisone	4-8 weeks onset
Surgical Debridement + Haglund Exostectomy	Level III	Debride calcification; remove posterior calcaneal prominence; reattach Achilles if needed	75-85% good-to-excellent at 2 years	3-6 months recovery; longer if tendon detached

Quick answer: Treatment for insertional achilles tendinopathy heel pain bone spur treatment follows a stepwise approach: 1) conservative care first (rest, ice, supportive footwear, OTC anti-inflammatories), 2) physical therapy and targeted exercises, 3) in-office treatments (injections, custom orthotics) if conservative fails at 4-6 weeks, 4) surgery for refractory cases. Most patients resolve at step 1 or 2. Call (810) 206-1402.

https://www.youtube.com/watch?v=8opvH3qxkW4

Insertional Achilles Tendinopathy: A Distinct Condition

Insertional Achilles tendinopathy (IAT) is a painful degenerative condition affecting the distal 2 cm of the Achilles tendon — the zone where the tendon inserts into the posterior calcaneus (heel bone). It is critically distinct from midportion Achilles tendinopathy (which occurs 2–6 cm above the heel) in terms of pathology, symptoms, and — most importantly — treatment.

One of the most important clinical points Dr. Tom Biernacki emphasizes: the Alfredson eccentric drop protocol that is highly effective for midportion tendinopathy is contraindicated for insertional disease. Eccentric drops performed below horizontal increase tendon-bone interface compression and reliably worsen insertional symptoms. Patients and providers who apply midportion protocols to insertional disease frequently prolong and worsen the condition.

Pathology: What Happens at the Insertion

At the insertion, the Achilles tendon transitions from tendon to fibrocartilage to bone — a zone called the enthesis. In insertional Achilles tendinopathy, this transition zone degenerates, with disorganized collagen, calcium deposition, and reactive bone formation (a posterior calcaneal spur, also called a Haglund deformity or “pump bump”). The combination of tendon degeneration and bony impingement on the posterior heel creates the characteristic pain pattern.

Retrocalcaneal bursitis — inflammation of the bursa between the Achilles tendon and the calcaneus — frequently coexists with IAT and contributes to both symptoms and difficulty with heel counter footwear.

Symptoms

IAT produces pain and swelling directly at the back of the heel — at the Achilles attachment — rather than the “zone” tenderness of midportion tendinopathy. Symptoms are classically worst with the first steps in the morning (similar to plantar fasciitis) and after periods of rest, then improve somewhat with light activity before worsening again with prolonged exertion. Shoe heel counter pressure — even from running shoes — directly compresses the inflamed insertion and Haglund spur, producing sharp, immediate pain.

A visible bony bump at the back of the heel (the Haglund deformity) is common. In severe cases, calcification within the tendon itself (intratendinous calcification) is visible on X-ray.

Diagnosis

Dr. Biernacki diagnoses IAT through history, physical examination, and imaging. Weight-bearing lateral X-rays of the heel demonstrate the posterior calcaneal spur and any intratendinous calcification. Diagnostic ultrasound provides real-time assessment of tendon fiber integrity, bursitis, and Haglund spur dimensions. MRI offers superior soft tissue detail for pre-surgical planning.

Conservative Treatment

Heel lift orthotics: A 6–10 mm heel lift reduces Achilles tendon tension and decreases calcaneal dorsiflexion at the insertion — directly reducing impingement stress. This is the cornerstone of conservative IAT management.

Open-back footwear: Removing heel counter pressure is essential. Clogs, sandals, or cut-away heel counter shoes eliminate the direct mechanical compression of the Haglund spur that causes pain with shoe wear. Even temporarily switching to backless shoes during acute flares accelerates recovery.

Isometric and isotonic exercises (above horizontal only): Calf strengthening performed with the heel ABOVE horizontal (on a step, loading into dorsiflexion only to the horizontal position) appropriately loads the tendon without compressing the insertion. This modified protocol, described by Alfredson and colleagues for IAT, differs critically from the drop-below-horizontal eccentric protocol used for midportion tendinopathy.

Extracorporeal shockwave therapy (ESWT): High-energy shockwave is well-supported for IAT — multiple trials demonstrate significant pain reduction and functional improvement. ESWT directly targets calcifications and stimulates healing at the enthesis.

Corticosteroid injections: Unlike midportion tendinopathy, corticosteroid injections into the retrocalcaneal bursa (not the tendon itself) are appropriate for IAT with bursitis. Ultrasound guidance ensures precise bursal placement, avoiding tendon injection. Injecting directly into the Achilles tendon at the insertion is avoided due to rupture risk.

Surgical Treatment

When 3–6 months of conservative care fails, surgery produces excellent outcomes for IAT. The procedure involves detaching the Achilles tendon from the calcaneus, resecting the Haglund spur and any intratendinous calcifications, debriding the degenerative tendon tissue, and reattaching the tendon with suture anchors. Recovery involves a period of non-weight-bearing followed by gradual rehabilitation over 4–6 months. Patient satisfaction rates exceed 80% at 1 year.
